330130-00-05-05-02-00 3300 XL Standard Extension Cable

Overview

Place of Origin:	USA
Brand Name:	Bently Nevada
Model Number:	330130-00-05-05-02-00
Packaging Details:	Original new Factory Sealed
Delivery Time:	5-7 days
Payment Terms:	T/T
Supply Ability:	In stock

Quick Detail

Description

330130-00-05-05-02-00 is a 4.5-meter armored extension cable designed for 3300 XL 8 mm proximity transducer systems used in industrial automation and rotating machinery monitoring. The 330130-00-05-05-02-00 adopts 75 Ω triaxial cable with FEP insulation, delivering a typical capacitance of 69.9 pF/m and output resistance of 50 Ω. These electrical values maintain accurate signal transmission across long field wiring up to 305 meters while supporting a 0–10 kHz frequency response and a 2 mm linear measurement range.

The 330130-00-05-05-02-00 operates within –52°C to +177°C, allowing installation near turbines, compressors, and pumps exposed to high heat. With supply sensitivity below 2 mV per volt change and support for 0.2 to 1.5 mm² field wiring, 330130-00-05-05-02-00 ensures consistent eddy current signal extension in automation systems. The armored cable and connector protector reduce mechanical damage during installation and maintenance.

Applications

Applications in Turbine Shaft Vibration Monitoring

In steam and gas turbines, 330130-00-05-05-02-00 connects 8 mm proximity probes to monitoring modules for shaft vibration tracking. With a typical capacitance of 69.9 pF/m and support for up to 305 meters of total field wiring, 330130-00-05-05-02-00 maintains accurate signal transmission within the 0–10 kHz frequency response range. The 2 mm linear range allows precise radial displacement measurement, while the 50 Ω output resistance of 330130-00-05-05-02-00 helps preserve waveform accuracy during long-distance routing inside turbine enclosures.

Applications in Compressor Axial Position Measurement

For centrifugal compressors, 330130-00-05-05-02-00 transfers axial position signals from the probe to the control cabinet. The supply sensitivity of less than 2 mV per volt change ensures that 330130-00-05-05-02-00 delivers consistent output even when power supply fluctuation occurs. The 75 Ω triaxial FEP construction of 330130-00-05-05-02-00 reduces signal attenuation across the 4.5-meter cable length, supporting accurate thrust position monitoring within the 2 mm measurement span.

Applications in Pump Bearing Clearance Detection

In fluid-film bearing pumps, 330130-00-05-05-02-00 extends eddy current signals used to measure bearing clearance and shaft displacement. Operating from –52°C to +177°C, 330130-00-05-05-02-00 can be installed close to high-temperature pump casings. The controlled capacitance value of 69.9 pF/m ensures that high-frequency vibration components up to 10 kHz are transmitted without distortion.

Applications in Generator Speed and Keyphasor Signal Transmission

For generator speed measurement and Keyphasor reference input, 330130-00-05-05-02-00 transmits pulse signals with low electrical loss. The 50 Ω output resistance and less than 2 mV/V supply variation of 330130-00-05-05-02-00 allow accurate rotational speed detection during load transitions. The armored connector protector of 330130-00-05-05-02-00 supports secure installation in generator frames where mechanical stress is common.

Specifications

Competitive Advantage

Competitive Advantage in Long Distance Industrial Layouts

With a 4.5-meter cable length and support for up to 305 meters of field wiring, 330130-00-05-05-02-00 enables flexible routing in large automation plants. The 69.9 pF/m capacitance specification of 330130-00-05-05-02-00 ensures that cumulative capacitance remains within acceptable limits even in extended installations.

Competitive Advantage in High Temperature Machinery Zones

The –52°C to +177°C operating range allows 330130-00-05-05-02-00 to function near turbines, compressors, and pumps without additional thermal barriers. FEP insulation used in 330130-00-05-05-02-00 resists thermal degradation under continuous exposure to elevated process temperatures.

Competitive Advantage in Mechanical Protection During Cable Routing

The armored design of 330130-00-05-05-02-00 provides additional resistance against pulling force and abrasion during installation. Combined with connector protection, 330130-00-05-05-02-00 reduces the risk of signal interruption caused by cable damage in heavy industrial automation environments.

Competitive Advantage in Accurate High Frequency Signal Transmission

The 75 Ω triaxial structure of 330130-00-05-05-02-00, together with a 50 Ω output resistance and 0–10 kHz frequency response capability, allows 330130-00-05-05-02-00 to transmit vibration, position, and speed signals with measurable electrical control across automated machinery protection systems.
