Overview
330103-00-05-10-01-05 3300 XL 8 mm Proximity Probes
At a Glance
Place of Origin: |
USA |
Brand Name: |
Bently Nevada |
Model Number: |
330103-00-05-10-01-05 |
Minimum Order Quantity: |
1 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Product Overview
Description
The 330103-00-05-10-01-05 3300 XL 8 mm Proximity Probes is a high-precision eddy current sensing solution specifically engineered for continuous condition monitoring in critical rotating machinery. As a core component of the 3300 XL series, this probe converts variations in the distance between the probe tip and a conductive target surface into a stable, linear voltage output, enabling accurate measurement of shaft vibration, axial position, radial displacement, and mechanical movement.
Designed to meet the demanding requirements of industrial environments, the 3300 XL 8 mm Proximity Probes delivers consistent measurement performance across a wide operating temperature range from -50°C to +170°C, ensuring reliable data acquisition in both low-temperature outdoor installations and high-temperature turbine or compressor enclosures. Its 2 mm (80 mils) linear range supports precise detection of both static position changes and dynamic vibration signals, making it suitable for long-term machine health assessment and predictive maintenance strategies.
The mechanical construction of the 330103-00-05-10-01-05 3300 XL 8 mm Proximity Probes emphasizes durability and installation flexibility. The probe case is manufactured from AISI 303/304 stainless steel, providing excellent resistance to corrosion, oil exposure, dust, and mechanical wear. The probe tip is fabricated from polyphenylene sulfide (PPS), offering thermal stability and electrical insulation for stable eddy current generation. With an unthreaded length of 0 mm and an overall case length of 50 mm, the probe supports precise mounting alignment in compact machinery layouts.
Key Functions
Applications
1.Rotating Machinery Condition Monitoring
The 3300 XL 8 mm Proximity Probes is widely used for vibration and displacement monitoring of rotating equipment such as turbines, compressors, pumps, motors, and gearboxes. Its 2 mm linear range enables accurate detection of shaft vibration and radial movement.
2.Shaft Position and Axial Displacement Measurement
With stable output characteristics and low supply sensitivity, the probe is ideal for monitoring axial shaft position, thrust movement, and mechanical alignment in fluid-film bearing systems.
3.Industrial Environments with Harsh Conditions
Thanks to stainless steel housing, PPS probe tip, and wide temperature tolerance, the 330103-00-05-10-01-05 3300 XL 8 mm Proximity Probes performs reliably in environments exposed to heat, oil, dust, and continuous mechanical stress.
4.Hazardous and Regulated Areas
With CSA, ATEX, and IECEx approvals, the probe supports safe deployment in potentially explosive or regulated industrial zones.
Official Specifications
Quick Detail
|
Agency Approval Option: |
CSA, ATEX, IECEx Approvals |
|
Unthreaded Length Option : |
0 mm |
|
Overall Case Length Option : |
50 mm |
|
Total Length Option: |
1.0 meter (3.3 feet) |
|
Connector and Cable-Type Option: |
Miniature coaxial ClickLoc connector with connector protector, standard cable |
|
Dimension: |
1.8x1.5x121cm |
|
Weight: |
0.06kg |
Specifications
|
Operating Temperature Range: |
-50°C to +170°C (-61°F to+340°F) |
|
Linear Range: |
2 mm (80 mils) |
|
Output Resistance: |
50 Ω |
|
Supply Sensitivity: |
Less than 2 mV change in output voltage per volt change in input voltage. |
|
Power: |
Requires -17.7 Vdc to -25 Vdc |
|
Probe Tip Material: |
Polyphenylene sulfide (PPS) |
|
Probe Case Material: |
AISI 303 or 304 stainless steel(SST) |
Frequently Asked Questions
What is the model number?
The listed model number is 330103-00-05-10-01-05.
What is the brand name?
The listed brand name is Bently Nevada.
What is the place of origin?
The listed place of origin is USA.
What are the packaging details?
The listed packaging details are Original new Factory Sealed.
What is the delivery time?
The listed delivery time is 5-7 days.
Is this model available?
The listed supply status is In stock.
What are the payment terms?
The listed payment terms are T/T.
Compatibility & Ordering Notes
Competitive Advantage
1.High Measurement Stability and Accuracy
The 3300 XL 8 mm Proximity Probes provides linear, repeatable output with low sensitivity to supply voltage variation, ensuring dependable vibration and position data for long-term monitoring.
2.Compact Design with Flexible Installation
A 50 mm overall case length, 0 mm unthreaded section, and miniature ClickLoc connector allow easy installation in confined machinery spaces without compromising signal integrity.
3.Industrial-Grade Durability
Stainless steel construction and PPS probe tip deliver superior resistance to corrosion, wear, and thermal stress, extending service life and reducing maintenance costs.
4.Certified for Global Industrial Use
Multiple international approvals (CSA, ATEX, IECEx) enable deployment across global industrial projects, simplifying compliance and system integration.
