Overview
Place of Origin: |
Sweden |
Brand Name: |
ABB |
Model Number: |
07ZE63R302 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Quick Detail
|
Model: |
07ZE63R302 |
|
Product Type |
Central Unit Module |
|
Structure: |
Modular |
|
Installation Method: |
On-site installation |
|
Rated Operating Voltage: |
440 V |
|
Rated Operating Current: |
24 A |
|
Power Supply Voltage: |
AC |
|
Operating Voltage Type: |
AC/DC |
|
Number of Contacts: |
4, no normally open contacts |
|
Maximum Load Capacity: |
Incandescent 1000 W, Fluorescent 700 VA, Dual-circuit Fluorescent 1400 VA |
Description
The ABB 07ZE63R302 Central unit modules are core control devices in the field of industrial automation. Employing a multi-core architecture, they are specifically designed for real-time data processing needs in complex industrial scenarios. With their high reliability and modular design, these modules can be seamlessly integrated into production line control, energy management systems, and smart manufacturing solutions, providing users with stable and efficient computing support.
Applications
Suitable for packaging machinery,plastics machinery,dyeing and printing,presses,lifting machinery,energy optimization,smart buildings,marine equipment control,wind power systems,municipal pumping stations,air conditioning and refrigeration systems,municipal engineering,environmental protection projects,steel and metallurgy,petrochemicals,and power automation.
Features
Easy Installation:Mounts on 35mm mounting rails with a mounting depth of 58mm according to DIN EN 60715.
Superior Performance:Magnetic actuation ensures silent,buzz-free switching.Features include a switch position indicator,integrated coil circuitry,and support for auxiliary switches.Coil overvoltage protection up to 5kV is provided,ensuring high switching capacity and a long service life.
Easy Connection:Features push-button quick-clamping,large connections with open-frame terminals,and contact protection that complies with VDE 0106 Part 100.
Advantages
The 07ZE63R302 features an industrial-grade wide-temperature design. Its unique heat dissipation structure, optimized through finite element analysis, ensures temperature fluctuations are controlled within ±2℃ during full-load operation. It supports ABB's proprietary System 800xA integrated architecture, enabling seamless integration with AC500 series PLCs and 800xA DCS systems. In redundant configurations, data synchronization latency between primary and backup units is less than 50ms, with a smooth switching process. It is equipped with dual network port redundancy, supports the MRP ring network protocol, and has a network fault recovery time of <20ms. Furthermore, with the pre-installed ABB Control Builder M software platform, users can program according to the IEC 61131-3 standard, supporting multiple programming languages such as Structured Text (ST) and Ladder Diagram (LD).
FAQ
Q: Is 07ZE63R302 new or refurbished?
A: All our products are original and brand new with a 1-year warranty.
Q: How many days will the 07ZE63R302 arrive in my hands if I place the order now?
A: As soon as we receive the payment, we will ship the product immediately. It usually takes 3–5 days from China to your hands.
Q: Can you ship the 07ZE63R302 to my country?
A: Please don't worry. We can ship the goods worldwide.
Q: What payment method do you use?
A: We usually use T/T (Telegraphic Transfer), and the payment can typically be received within 1–2 days.
Q: Can I contact you by email?
A: You can contact me online to get my email address.
