Overview
Place of Origin: |
USA |
Brand Name: |
HONEYWELL |
Model Number: |
TK-FFIF01 51403420-275 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Parameter |
Value |
|
Model |
TK-FFIF01 51403420-275 |
|
Product Type |
Fieldbus Interface Module |
|
Dimensions |
12 × 8 × 6 cm |
|
Weight |
0.42 kg |
|
Coating |
Yes (coated) |
|
Physical Interface |
H1 FOUNDATION Fieldbus |
|
Number of H1 Networks per Module |
2 |
|
H1 Network Speed |
31.25 kbps |
|
Max Devices per H1 Network |
16 |
|
Available Macrocycle Periods |
250 ms, 500 ms, 1 s, 2 s, 4 s, 8 s, 16 s, 32 s |
|
Module Connection to RTP |
TC-FFCxxx Fieldbus RTP Cable |
Description
The TK-FFIF01 51403420-275 is a Fieldbus Interface Module (FIM) used to connect H1 FOUNDATION Fieldbus field devices to a centralized industrial control system. It can convert management commands issued by the control system into signals that the field instruments can recognize and send them out, while simultaneously sending the measurement values and operating status returned by the field instruments back to the main control equipment.
Applications
Petrochemical plants: Corrosion-resistant coated design ensures stable connection of Fieldbus transmitters in harsh refinery environments.
Fine chemical plants: Supports multi-device fieldbus topology for centralized valve and actuator control near reactors.
Thermal power plants: Provides real-time Fieldbus communication for emission control and turbine auxiliary systems.
Pharmaceutical & semiconductor plants: Enables digital Fieldbus diagnostics and remote asset monitoring in cleanroom instrumentation systems.
Troubleshooting
Frequent H1 bus drops/packet loss: Check terminating resistor and bus power voltage. If normal, verify each H1 segment does not exceed 16 Fieldbus devices.
Channel failure/red alarm: Inspect TC-FFCxxx RTP cable connection or damage. Swap module links to isolate board port vs. external wiring fault.
Macrocycle delay/conflict: High device load may cause overlap at 250 ms. Adjust cycle to 500 ms or 1 s to balance bus bandwidth.
FAQ
Q: Does TK-FFIF01 51403420-275 have a coating?
A: Yes, it has a coating.
Q: How many H1 networks does each TK-FFIF01 51403420-275 module include?
A: It includes 2 H1 networks.
Q: What is the H1 network transmission speed of TK-FFIF01 51403420-275?
A: The transmission speed is 31.25 kbps.
Q: How many devices can each H1 network of TK-FFIF01 51403420-275 support?
A: Each H1 network supports up to 16 devices.
Q: What macrocycle periods are available for TK-FFIF01 51403420-275?
A: It supports 250 ms, 500 ms, 1 s, 2 s, 4 s, 8 s, 16 s, and 32 s.
