6ES7352-5AH01-0AE0 SIMATIC S7-300 FM 352-5 High-Speed Boolean Processor
The FM 352-5 is a high-speed Boolean processor with twelve digital inputs, eight digital outputs, onboard logic execution and a SIMATIC Micro Memory Card for loading the configured FPGA program.
At a Glance
| Brand | Siemens |
|---|---|
| Model | 6ES7352-5AH01-0AE0 |
| Product Type | High-speed Boolean processor function module |
| Core Function | Executes time-critical Boolean logic independently of the CPU using onboard digital I/O |
| Application or Compatible Series | S7-300 and approved ET 200M systems requiring deterministic high-speed logic |
Exact Identification
Match 6ES7352-5AH01-0AE0 character by character and confirm the complete SIMATIC S7-300 FM 352-5 High-Speed Boolean Processor designation.
Interface Arrangement
Confirm the installed supply, ports, field connections and required accessories before wiring the replacement.
Configuration Check
Preserve the approved engineering project, network parameters and application data used by the installed system.
Product Overview
The FM 352-5 is a high-speed Boolean processor with twelve digital inputs, eight digital outputs, onboard logic execution and a SIMATIC Micro Memory Card for loading the configured FPGA program.
Executes fast binary logic locally so time-critical functions do not depend on the CPU scan cycle. Twelve inputs and eight outputs connect the module directly to the machine signals used by the Boolean program. The FPGA image is loaded from a programmed SIMATIC Micro Memory Card after power-up or memory reset.
Key Functions
Independent Boolean Processing
Executes fast binary logic locally so time-critical functions do not depend on the CPU scan cycle.
Integrated Digital I/O
Twelve inputs and eight outputs connect the module directly to the machine signals used by the Boolean program.
Memory-Card Program Loading
The FPGA image is loaded from a programmed SIMATIC Micro Memory Card after power-up or memory reset.
Official Specifications
| Module Designation | FM 352-5 |
|---|---|
| Digital Inputs | 12 |
| Digital Outputs | 8 |
| Rated Supply Voltage | 24 V DC |
| Load Voltage 1L+ Input Current | 60 mA typical, 150 mA maximum |
| Load Voltage 2L+ Input Current | 60 mA typical, 200 mA maximum without load |
| Load Voltage 3L+ Input Current | 80 mA typical, 600 mA maximum with encoder |
| Backplane-Bus Current at 5 V DC | 135 mA typical |
| 5 V Encoder Supply | Available |
| Encoder-Supply Protection | Electronic overload protection |
| Program Storage Medium | SIMATIC Micro Memory Card |
| Operating Modes | RUN, STOP and MRES |
| ET 200M Configuration | Supported with approved IM 153 interface modules |
| Compliance | IEC 1131-2 and CE requirements |
Frequently Asked Questions
Why is 6ES7352-5AH01-0AE0 used instead of executing the logic in the CPU?
It processes time-critical Boolean functions locally and independently of the controller scan cycle.
How many machine signals can connect directly to 6ES7352-5AH01-0AE0?
The module provides twelve digital inputs and eight digital outputs.
What memory medium is required by 6ES7352-5AH01-0AE0?
Use the programmed SIMATIC Micro Memory Card containing the valid FPGA application image.
What happens when the memory of 6ES7352-5AH01-0AE0 is reset?
The outputs turn off, counters and timers reset, and the FPGA reloads its image from the memory card.
Can the memory card be removed while 6ES7352-5AH01-0AE0 is running?
Operation can continue until a power cycle, but the module then requires a valid card to return to RUN.
Can 6ES7352-5AH01-0AE0 be used in an ET 200M station?
Yes; configure it only behind an approved IM 153 interface module and with the required engineering add-on.
What should be saved before replacing 6ES7352-5AH01-0AE0?
Preserve the STEP 7 project, Boolean program, memory-card image, I/O assignments and module parameters.
Compatibility & Ordering Notes
Compatibility Checklist
- Use the module only in a supported S7-300 rack or approved ET 200M station.
- Keep the programmed Micro Memory Card and verified engineering project with the replacement.
- Validate every fast input, output and encoder circuit before enabling the Boolean application.
