Overview
Place of Origin: |
USA |
Brand Name: |
Parker |
Model Number: |
GV6-U12E-NK |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Specifications
|
Dimensions: |
8.5x17.5x20.6 cm |
|
Weight: |
1.65 kg |
|
Drive Axis Type: |
Single Axis Technology |
|
Product Series: |
Gemini |
|
Input Voltage: |
1*120 to 240 VAC |
|
Continuous Output Current Rating: |
6 A (15 A peak for 6s) |
|
Compatible Motor Type: |
Brushless Servo, Direct Drive Servo, Frameless Servo, Linear Servo |
|
Compatible Feedback Device: |
Resolver, Incremental Encoder |
|
Modes of Control: |
Programmable Control - Proprietary Language, Electronic Gearing, Electronic CAM, Position Control (External Command), Velocity Control (External Command), Torque Control (External Command), Analog Command Input, Step/Direction Command Input |
|
Communication Interface: |
RS232/RS485, Ethernet TCP/IP |
|
Operating Temperature: |
0 to 50 °C (32 to 122 °F) |
|
Maximum Shaft Power: |
1.75 kW (continuous) |
|
Power Output Rating: |
2.3 kVA |
|
Feedback Options: |
Quadrature Encoder, Resolver |
|
Control Options: |
±10V and Step/Direction, Basic Controller or Multitasking 6K Motion Controller |
|
Specifications Met: |
CE (EMC & LVD), UL Recognized, cUL Recognized |
Description
The Gemini GV-series single-axis servo drives and servo drive/controllers are available with 3 levels of control across 6 power ratings, offering power outputs from 0.6 to 18kVA and input power supply options of 1*120VAC to 1/3*240VAC. The Gemini GV servo drives accept accept industry standard ±10V torque/velocity commands, step and direction or CW/CCW position command signals and feature simplified configuration and tuning, plus digital notch filters to help eliminate mechanical resonance. The Gemini GV is easily configurable via RS232/485 using Parker's Motion Planner™ on a PC or Pocket Motion Planner™ on a Window's CE™-based palm PC. Tuning and configuration is made easy - it requires only the motor and some basic load information to permit the drive to determine baseline-tuning gains. These are simple parameter entries the user can complete with the help of the front-end software tools. Users also have the ability to override these parameters for special application requirements.
Physical
Compatible with a wide selection of brushless servo motors, such as the Parker SM, BE, NeoMetric, J and M Series motors
Diagnostic LEDs for drive status, firmware, download and 24VDC control power active
Wide range of PWM frequencies for linear motor support
Supports linear servo motors, such as the Parker LXR and SL motor series
Three input power ranges available - Low (120VAC), Universal (120/240VAC) and High (240VAC)
Features
Five Power Ranges for up to 5.9 kW of Continuous Power
Simplified Tuning and Configuration
Variable Resolution for the Encoder Out as Well as the Command Input
Wide Range of PWM Frequencies for Linear Motor Support
Short Circuit Protection, Brownout Protection, Over Temperature Shutdown
Diagnostic LEDs
The Gemini GV features the following
Torque, velocity, step & direction and CW/CCW modes
Encoder tracking mode
Digital notch filters provide the tools to eliminate mechanical resonance
Sinusoidal commutation with encoder or resolver feedback
Simplified tuning and configuration
Variable resolution for encoder signal output as well as the command input
Wide range of PWM frequencies for linear motor support
Three input power ranges available: low – 120V, universal – 120/240V, and high – 240V
Diagnostic LEDs for drive status, firmware download, and optional keep alive mode
Protection
Short-circuit protection – phase-to-phase and phase-to-ground
Inrush current protection
Drive over-voltage protection
Drive under-voltage (brownout) protection
Drive and motor over-temperature protection
Current-foldback protection
Regeneration protection
