Overview
Place of Origin: |
USA |
Brand Name: |
Bently Nevada |
Model Number: |
330103-00-11-10-02-05 |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
5-7 days |
Payment Terms: |
T/T |
Supply Ability: |
In stock |
Quick Detail
|
Unthreaded Length Option(Minimum unthreaded length): |
00 mm |
|
Overall Case Length Option(Minimum case length): |
110 mm |
|
Total Length Option: |
1.0 meter (3.3 feet) |
|
Connector and Cable-Type Option: |
Miniature coaxial ClickLoc connector, standard cable |
|
Agency Approval Option: |
CSA, ATEX, IECEx Approvals |
|
Probe Case Thread: |
M10x1 |
|
Maximum Length of Thread Engagement: |
15 mm |
|
Dimension: |
1.8x1.6x117cm |
|
Weight: |
0.1kg |
Description
Radial Vibration Monitoring on Industrial Shafts
330103-00-11-10-02-05 measures radial vibration on turbines, compressors, and pumps. With a linear range of 2 mm (80 mils) and a 50 Ω output, 330103-00-11-10-02-05 provides accurate real-time signals for predictive maintenance, reducing unplanned downtime in rotating machinery.
Axial Shaft Displacement Measurement
330103-00-11-10-02-05 tracks axial (thrust) movement on shafts using its 110 mm case and M10x1 probe threads with 15 mm maximum thread engagement. Signals from 330103-00-11-10-02-05 ensure precise alignment and safe operation of motors, gearboxes, and pumps.
Integration with Automation and Control Systems
Equipped with a miniature coaxial ClickLoc connector and standard cable, 330103-00-11-10-02-05 transmits vibration and position signals directly to automation systems. Supply sensitivity of less than 2 mV per volt change ensures consistent signal output for industrial control applications.
High-Temperature and Harsh Environment Operation
330103-00-11-10-02-05 functions from -52°C to +177°C (-62°F to +350°F) and supports CSA, ATEX, and IECEx approvals. This allows 330103-00-11-10-02-05 to operate safely in petrochemical plants, offshore facilities, and power generation environments.
Field Wiring and Extension Options for Remote Monitoring
330103-00-11-10-02-05 supports field wiring from 0.2 to 1.5 mm² (16–24 AWG) and extension cables up to 1.0 meter (3.3 feet). Using 330103-00-11-10-02-05, operators can install probes in challenging locations while maintaining accurate vibration and displacement readings.
Applications
Radial Vibration Monitoring on Industrial Shafts
330103-00-11-10-02-05 measures radial vibration on turbines, compressors, and pumps. With a linear range of 2 mm (80 mils) and a 50 Ω output, 330103-00-11-10-02-05 provides accurate real-time signals for predictive maintenance, reducing unplanned downtime in rotating machinery.
Axial Shaft Displacement Measurement
330103-00-11-10-02-05 tracks axial (thrust) movement on shafts using its 110 mm case and M10x1 probe threads with 15 mm maximum thread engagement. Signals from 330103-00-11-10-02-05 ensure precise alignment and safe operation of motors, gearboxes, and pumps.
Integration with Automation and Control Systems
Equipped with a miniature coaxial ClickLoc connector and standard cable, 330103-00-11-10-02-05 transmits vibration and position signals directly to automation systems. Supply sensitivity of less than 2 mV per volt change ensures consistent signal output for industrial control applications.
High-Temperature and Harsh Environment Operation
330103-00-11-10-02-05 functions from -52°C to +177°C (-62°F to +350°F) and supports CSA, ATEX, and IECEx approvals. This allows 330103-00-11-10-02-05 to operate safely in petrochemical plants, offshore facilities, and power generation environments.
Field Wiring and Extension Options for Remote Monitoring
330103-00-11-10-02-05 supports field wiring from 0.2 to 1.5 mm² (16–24 AWG) and extension cables up to 1.0 meter (3.3 feet). Using 330103-00-11-10-02-05, operators can install probes in challenging locations while maintaining accurate vibration and displacement readings.
Specifications
|
Operating and Storage Temperature: |
-52°C to +177°C (-62°F to +350°F) |
|
Supply Sensitivity: |
Less than 2 mV change in output voltage per volt change in input voltage |
|
Output Resistance: |
50 Ω |
|
Extension Cable Capacitance: |
69.9 pF/m (21.3 pF/ft) typical |
|
Field Wiring: |
0.2 to 1.5 mm2 (16 to 24 AWG) |
|
Linear Range: |
2 mm (80 mils) |
Competitive Advantage
1. High Accuracy and Linear Response
The 2 mm linear range with supply sensitivity under 2 mV/V ensures reliable measurement for automated condition monitoring systems.
2. Robust Mechanical Integrity
TipLoc and CableLoc designs provide 330 N pull strength, ensuring probe stability and reducing maintenance in industrial automation setups.
3. Wide Operating Range
Supports extreme temperatures (-52°C to +177°C) and hazardous approvals (CSA, ATEX, IECEx), ensuring reliable operation in diverse industrial environments.
